Post + Beam Light Stand
CONFIGURE YOUR FIXTURE ➔
REQUEST A QUOTE ➔
aaline’s Post + Beam Series is designed for focused, high-quality lighting for high-traffic, commercial, and institutional projects. Enhanced with anti-glare carved visors (UGR<16) and 90+ CRI LED chips, the Post + Beam Series holds the highest-performing light fixtures in their class.
The Post + Beam Light Stand combines locally sourced, FSC-certified hardwood with metal in a cantilever or t-stem design. The Light Stand provides various colours and material finishes to achieve specific appearances.
SERIES: LW-EB
COLLECTION: PB
MODEL: LS01 | LS02
LUMEN OUTPUT + CONSUMPTION:
LS01 | 536 lm/ft, 9.6 W/ft
LS02 | 1072 lm/ft, 19.2 W/ft
POWER INPUT: 110-277V AC, 50/60 Hz
OPTICS: Polycarbonate tube diffuser
CONFIGURE YOUR FIXTURE ➔
REQUEST A QUOTE ➔
aaline’s Post + Beam Series is designed for focused, high-quality lighting for high-traffic, commercial, and institutional projects. Enhanced with anti-glare carved visors (UGR<16) and 90+ CRI LED chips, the Post + Beam Series holds the highest-performing light fixtures in their class.
The Post + Beam Light Stand combines locally sourced, FSC-certified hardwood with metal in a cantilever or t-stem design. The Light Stand provides various colours and material finishes to achieve specific appearances.
SERIES: LW-EB
COLLECTION: PB
MODEL: LS01 | LS02
LUMEN OUTPUT + CONSUMPTION:
LS01 | 536 lm/ft, 9.6 W/ft
LS02 | 1072 lm/ft, 19.2 W/ft
POWER INPUT: 110-277V AC, 50/60 Hz
OPTICS: Polycarbonate tube diffuser
CONFIGURE YOUR FIXTURE ➔
REQUEST A QUOTE ➔
aaline’s Post + Beam Series is designed for focused, high-quality lighting for high-traffic, commercial, and institutional projects. Enhanced with anti-glare carved visors (UGR<16) and 90+ CRI LED chips, the Post + Beam Series holds the highest-performing light fixtures in their class.
The Post + Beam Light Stand combines locally sourced, FSC-certified hardwood with metal in a cantilever or t-stem design. The Light Stand provides various colours and material finishes to achieve specific appearances.
SERIES: LW-EB
COLLECTION: PB
MODEL: LS01 | LS02
LUMEN OUTPUT + CONSUMPTION:
LS01 | 536 lm/ft, 9.6 W/ft
LS02 | 1072 lm/ft, 19.2 W/ft
POWER INPUT: 110-277V AC, 50/60 Hz
OPTICS: Polycarbonate tube diffuser
-
DESIGNED WITH PURPOSE
The Post + Beam Series is designed and detailed for libraries, reading rooms, offices, and interior spaces that focus and light quality is required.CUSTOMIZABLE + MODULAR
Envisioned by Fishtnk’s team, the system is designed as a kit of parts that can be customized and fine-tuned to look and perform exactly as required by the project designers, engineers, and architects.HIGH-PERFORMANCE TECHNOLOGY
This Series is fine-tuned with smart controls and programmable technology to seamlessly integrate into building management platforms.SUSTAINABLE
Our products consist of 100% recyclable fixture components. -
PROFILE
1-3/4" W x 1-3/4" H
BEAM LENGTH [L]
20"
LIGHT DISTRIBUTION
Direct
Indirect
POST HEIGHT [H]
Total height in inches, Increments of 1"
Min. 16" - Max. 72"
PROGRAMMABLE DRIVER ➔
Integrated
RemoteDIMMING | ONSITE
0-10V
TRIAC/ELV
DALI
LUTRON Ecosystem
DIMMING | ONBOARD
Physical Dial
Occupancy Sensor [Touchless]
COLOUR TEMPERATURE ➔
2700K, 90+ CRI
3000K, 90+ CRI
3500K, 80 and 90+ CRI
4000K, 80 and 90+ CRI -
PROFILE
1-3/4" W x 1-3/4" H
BEAM LENGTH [L]
28-1/2"
LIGHT DISTRIBUTION
Direct
Indirect
POST HEIGHT [H]
Total height in inches, Increments of 1"
Min. 16" - Max. 72"
PROGRAMMABLE DRIVER ➔
Integrated
RemoteDIMMING | ONSITE
0-10V
TRIAC/ELV
DALI
LUTRON Ecosystem
DIMMING | ONBOARD
Physical Dial
Occupancy Sensor [Touchless]
COLOUR TEMPERATURE ➔
2700K, 90+ CRI
3000K, 90+ CRI
3500K, 80 and 90+ CRI
4000K, 80 and 90+ CRI -
